DIPON LuminaCast 3 Crystal Flow 3 kg - Ultra Low Viscosity Epoxy Resin, Thickness 10 mm
Code: 7300/003000Related products
Product detailed description
Crystal Flow 3 kg. Resin for laminating and surface coats.
Pack 3 kg — most popular pack — clocks, coasters and laminating. Exceptionally low-viscosity clear resin: it levels itself, smooths itself and wets the substrate perfectly. Layer 1–10 mm, refractive index > 1.59.
It levels itself. It smooths itself.
Crystal Flow is built for thin clear layers — surface coats, laminating and resin art, where perfect wetting is what matters.
Surface coats of boards & clocks
A thin glass-like layer over wood, paintings and photographs.
Resin art & laminating
Perfect substrate wetting without streaks or patches.
Floral coasters
Clear casting of dried flowers up to 10 mm.
How much resin for your project?
Click on a size — you will see the current price and availability right next to it.
and tests Most popular3 kgclocks, coasters
and laminating 7,5 kglarger boards
and series 15 kgstudio
and courses Best price/kg30 kgfull
production
A low viscosity that works for you.
140 mPa·s means the resin levels itself, degasses itself and wets wood, canvas and paper perfectly.
- Self-levelling and self-smoothing surface
- Perfect substrate wetting — no patches or streaks
- UV absorbers + HALS — no yellowing in the long term
- Very low shrinkage < 0.1 %
The same DNA as the whole LuminaCast range.
Every LuminaCast system is made at DIPON's own production site in Germany: UV absorbers + HALS additives against yellowing, a formulation free of substances on the sVHC and CoRAP lists, and degassing components more than 70 % from renewable sources.
- UV absorbers + HALS — no yellowing in the long term
- Free of sVHC and CoRAP substances
- The systems in the range combine in a project — each has its role
Parameters you can rely on
Measured at 23 °C, 200 g, 5–10 mm layer — source: DIPON TDS
Compatible with wood, concrete, glass, metal, glass and carbon fibre fabrics, natural stone, silica sand, marble and granite.
Your first lamination will work out too
Check the temperature
Material and surroundings at room temperature. High temperature = fast exotherm, yellowing and cracks.
Test the substrate
A preliminary compatibility test of the materials you are going to embed.
Weigh out exactly 2:1
Always by weight (100:50). Maximum deviation 0.1 % — more means a sticky film or a soft casting.
Mix twice for 3–4 minutes
Mix → pour into a clean container → mix again. Max. 300 rpm, ideally with with an Allway Helix mixer.
Pour it out and let it work
A 1–10 mm layer levels itself. You can demould after 16–24 hours.
⚠️ The most common mistake
Never mix by eye straight from bottles A and B. An inaccurate ratio = incomplete curing. Always weigh both components to the gram. Cleaning tools: acetone or universal thinner, immediately after use.
A set for small-scale making — resins that belong together
One studio, four roles: coasters, laminating, jewellery and slower effects. Combine them.
| LuminaCast 2Coaster CastDetail | LuminaCast 3 ★Crystal FlowThis product | LuminaCast 4Gem FlowDetail | LuminaCast 5Radiant FlowDetail | |
|---|---|---|---|---|
| Role in the project | Coasters, embedding and shapes | Laminating, surface coats and resin art | Jewellery and thicker small pours | Art with slower flow |
| Max. casting thickness | 15 mm | 10 mm | 20 mm | 20 mm |
| Working time | 35 min | 35 min | 55 min | 60 min |
| Viscosity (23 °C) | 290 mPa·s | 140 mPa·s | 890 mPa·s | 1330 mPa·s |
📊Compare the whole LuminaCast rangeAll 10 hardeners — viscosity, working time and casting thickness in one clear table▼
| Type | Viscosity* (23 °C) | Working time** | Max. casting thickness | Use |
|---|---|---|---|---|
| LC 1 Fast Set Primer | 120 mPa·s | 15 min | 7 mm | priming and sealing coat for wood, overpour after 60–120 min |
| LC 2 Coaster Cast | 290 mPa·s | 35 min | 15 mm | highly transparent embedding and shapes |
| LC 3 Crystal Flow ★ | 140 mPa·s | 35 min | 10 mm | laminating & resin art |
| LC 4 Gem Flow | 890 mPa·s | 55 min | 20 mm | art & embedding, thicker pours |
| LC 5 Radiant Flow | 1330 mPa·s | 60 min | 20 mm | art & embedding, slower flow |
| LC 6 Art Flow | 4100 mPa·s | 50 min | 20 mm | painting techniques, top coat, sealing |
| LC 7 Design Flow | 5500 mPa·s | 50 min | 20 mm | special spreading, thin layers |
| LC 8 Table Flow | 70 mPa·s | 180 min** | 5 cm | river tables, lamps, larger castings |
| LC 9 Ocean Flow | 50 mPa·s | 240 min** | 10 cm | river tables and very large castings |
| LC 10 Cell Flow | 2500 mPa·s | 50 min | 20 mm | cell effects, Petri art |
* Viscosity at 23 °C — it rises sharply as the temperature drops. ** Measured on 200 g; LC 8 and LC 9 on 500 g / 9 cm. Time to max. exotherm ≈ 2× the working time.
★★★★★ from those who already create
„absolutely satisfied, the epoxy is really amazing and very nice to work with“
Karel K. · verified purchase
„It smooths out beautifully, thanks to the low viscosity it is excellent for surface coats…“
Martin D. · verified purchase
„A great resin, nice to work with“
Martina J. · verified purchase
„Beautifully transparent resin. Dries quickly.“
Elena J. · verified purchaseHow much Crystal Flow resin do you need?
Enter the dimensions of your casting — we will calculate the amount, the component ratio and the best pack combination.
Frequently asked questions
How thick a layer can I pour?
1–10 mm in a single layer at 20 °C. Pour taller castings in layers — next layer after 8–12 hours.
Is it suitable for coating a painting or photo?
Yes — the low viscosity wets the substrate perfectly and creates a thin glass-like layer. Always test the substrate for compatibility first.
When can I take the casting out of the mould?
Demoulding after approx. 16–24 hours at 23 °C.
How much will 3 kg cast?
3 kg of mixture (components A + B) equals approximately 2.8 l of casting (density 1.07 kg/l). The calculator above works out the exact amount for your project.
Why is 3 kg the most popular pack?
It is the most versatile balance of quantity and storage — approx. 2.8 litres of mixture covers most common projects.
Your first surface coat starts here.
Additional parameters
| Category: | Epoxy Resins |
|---|---|
| Weight: | 3.28 kg |
| ? Processing time: | Short |
| Epoxy system: | LuminaCast 3 |
| Colour: | Clear, Highly transparent |
| Package weight: | 3 Kg |
| Refractive index: | > 1,59 |
| Food contact: | Yes |
| Max casting thickness: | 1 cm |
| ? UV Resistance: | Yes, Maximum |
| ? Temperature resistance: | 70 °C |
| ? Hardness: | 72 ShD |
| Type of use: | Jewellery making, Jewellery using silicone moulds, Making trays and platters, Casting, Lamination, Glass and carbon laminates, Stone carpets |
| Casting size: | Small castings |
| ? Viscosity (density): | Extremely low - liquid |
