DIPON LuminaCast 8 Table Flow 3 kg - Low Viscosity Epoxy Resin, Thickness 5 cm
Code: 7257/003000Related products
Product detailed description
Table Flow 3 kg. Resin for table tops and furniture.
Pack 3 kg — most popular pack — a lamp, a smaller board and medium castings. Crystal-clear casting epoxy resin for furniture: 2–5 cm in a single pour, 180 minutes of working time and an optional mixing ratio for higher strength. Refractive index > 1.59.
Furniture that works out the first time.
Table Flow is built for medium-sized castings — table tops, coffee tables, smaller rivers and lamps.
Coffee & side tables
A typical furniture casting of 2–5 cm in a single pour.
Table tops & smaller rivers
180 minutes to level and degas a large board.
Lamps & design objects
Large-volume casting with diamond clarity.
How much resin for your project?
Click on a size — you will see the current price and availability right next to it.
and small castings Most popular3 kga lamp or
a smaller board 7,5 kgcoffee
table 15 kgtable
board Best price/kg30 kgproduction
and series
Pour the whole board at once. Calmly.
The low viscosity (B 70 mPa·s) flows into every joint and wets the wood perfectly. And 180 minutes of working time means peace of mind for levelling, pigmenting and degassing a large board.
- Layer 2–5 cm in a single pour
- 180 minutes for mixing, pigmenting and degassing
- Very low shrinkage < 0.1 % — no lifted edges
- UV absorbers + HALS — no yellowing in the long term
Furniture that gets used.
Table Flow is the only one in the range to offer an optional 100:40 mixing ratio by weight for higher strength — for boards that have to take some punishment. The formulation is free of sVHC and CoRAP substances; after full chemical curing it may come into contact with food.
- Optional 100:40 ratio for higher strength
- Free of sVHC and CoRAP substances
- After full curing also suitable for serving boards
Parameters you can rely on
Measured at 23 °C, 500 g, height 90 mm — source: DIPON TDS
Compatible with wood, concrete, glass, metal, glass and carbon fibre fabrics, natural stone, silica sand, marble and granite.
Your first pour will work out too
Check the temperature
Surroundings 15–20 °C, material 20–24 °C. High temperature = fast exotherm, yellowing and cracks.
Test the substrate
A preliminary compatibility test of the materials you are going to embed.
Weigh out exactly 2:1
Always by weight (100:50), optionally 100:40 for higher strength. Keep the chosen ratio throughout the project.
Mix twice for 3–4 minutes
Mix → pour into a clean container → mix again. Max. 300 rpm, ideally with with an Allway Helix mixer.
Seal the mould and pour
DIPON PP tape or release wax. Then just pour — 2 to 5 cm at a time.
⚠️ The most common mistake
Never mix by eye straight from bottles A and B. An inaccurate ratio = incomplete curing. Always weigh both components to the gram. Cleaning tools: acetone or universal thinner, immediately after use.
A set for large castings — resins that belong together
One project, four roles: sealing the substrate, small repairs, medium and large pours. Combine them.
| LuminaCast 1Fast Set PrimerDetail | LuminaCast 4Gem FlowDetail | LuminaCast 8 ★Table FlowThis product | LuminaCast 9Ocean FlowDetail | |
|---|---|---|---|---|
| Role in the project | Sealing and priming coat | Small repairs and embedding | Table tops, smaller rivers and lamps | Deep river tables, large moulds and lamps |
| Max. casting thickness | 7 mm | 20 mm | 5 cm | 10 cm |
| Working time | 15 min | 55 min | 180 min | 240 min |
| Viscosity (23 °C) | 120 mPa·s | 890 mPa·s | 70 mPa·s | 50 mPa·s |
📊Compare the whole LuminaCast rangeAll 10 hardeners — viscosity, working time and casting thickness in one clear table▼
| Type | Viscosity* (23 °C) | Working time** | Max. casting thickness | Use |
|---|---|---|---|---|
| LC 1 Fast Set Primer | 120 mPa·s | 15 min | 7 mm | priming and sealing coat for wood, overpour after 60–120 min |
| LC 2 Coaster Cast | 290 mPa·s | 35 min | 15 mm | highly transparent embedding and shapes |
| LC 3 Crystal Flow | 140 mPa·s | 35 min | 10 mm | laminating & resin art |
| LC 4 Gem Flow | 890 mPa·s | 55 min | 20 mm | art & embedding, thicker pours |
| LC 5 Radiant Flow | 1330 mPa·s | 60 min | 20 mm | art & embedding, slower flow |
| LC 6 Art Flow | 4100 mPa·s | 50 min | 20 mm | painting techniques, top coat, sealing |
| LC 7 Design Flow | 5500 mPa·s | 50 min | 20 mm | special spreading, thin layers |
| LC 8 Table Flow ★ | 70 mPa·s | 180 min** | 5 cm | river tables, lamps, larger castings |
| LC 9 Ocean Flow | 50 mPa·s | 240 min** | 10 cm | river tables and very large castings |
| LC 10 Cell Flow | 2500 mPa·s | 50 min | 20 mm | cell effects, Petri art |
* Viscosity at 23 °C — it rises sharply as the temperature drops. ** Measured on 200 g; LC 8 and LC 9 on 500 g / 9 cm. Time to max. exotherm ≈ 2× the working time.
★★★★★ from those who already create
„High product quality, good handling“
Peter M. · verified purchase
„Great“
Michaela K. · verified purchase
„I am very satisfied, my first epoxy table with little flowers 🌸“
Jana J. · verified purchase
„Very satisfied.“
Branislav Ď. · verified purchaseHow much Table Flow resin do you need?
Enter the dimensions of your casting — we will calculate the amount, the component ratio and the best pack combination.
Frequently asked questions
How deep can I pour at once?
20–50 mm in a single layer at 20 °C. At a lower temperature and smaller volume even more — follow the TDS.
What is the optional 100:40 ratio for?
The standard ratio is 2:1 (100:50). A 100:40 ratio by weight gives higher strength — suitable for heavily used boards and furniture. Keep the chosen ratio throughout the pour.
Is it safe for dining tables?
The formulation is free of sVHC and CoRAP substances and after full chemical curing it may come into contact with food. Then treat the wooden part with a food-safe with Howard oil or with Wax-It-All wax.
How much will 3 kg cast?
3 kg of mixture (components A + B) equals approximately 2.8 l of casting (density 1.07 kg/l). The calculator above works out the exact amount for your project.
Why is 3 kg the most popular pack?
It is the most versatile balance of quantity and storage — approx. 2.8 litres of mixture covers most common projects.
Your table top starts here.
Additional parameters
| Category: | Epoxy Resins |
|---|---|
| Weight: | 3.24 kg |
| ? Processing time: | Long |
| Epoxy system: | LuminaCast 8 |
| Colour: | Clear, Highly transparent |
| Package weight: | 3 Kg |
| Refractive index: | > 1,59 |
| Food contact: | Yes |
| Max casting thickness: | 5 cm |
| ? UV Resistance: | Yes, Maximum |
| ? Temperature resistance: | 70 °C |
| ? Hardness: | 72 ShD |
| Type of use: | Table making, Coffee and side tables - medium, Serving boards, Lamp making, Casting, Flower casting/embedding |
| Casting size: | Medium castings |
| ? Viscosity (density): | Low - liquid |
