DIPON LuminaCast 7 Design Flow 3 kg - High Viscosity Epoxy Resin, Thickness 20 mm
Code: 7308/003000Related products
Product detailed description
Design Flow 3 kg. Resin for precise design without spreading.
Pack 3 kg — most popular pack — regular making of clocks, trays and geodes. The highest viscosity in the range: pigment artwork will not drift, lines stay lines and thin layers spread only where you want them. Refractive index > 1.59.
The design stays the design.
Design Flow is built for work where nothing may spread — geodes, precise lines, multidimensional textures.
Geode design
Layers and lines hold exactly where you place them.
Clocks & smaller products
Controlled spreading for clean transitions and details.
Decorated trays & frames
Textures and reliefs that keep their shape.
How much resin for your project?
Click on a size — you will see the current price and availability right next to it.
and tests Most popular3 kgregular
making 7,5 kglarger formats
and series 15 kgstudio
and courses Best price/kg30 kgfull
production
The highest viscosity in the range. Nothing drifts.
5500 mPa·s: pigment artwork will not drift, fine details and larger areas stay exactly as you designed them. From embedding fine pigments to multidimensional textures.
- 5500 mPa·s — pigments stay in place
- Thin layers with controlled spreading
- Multidimensional textures and reliefs
- UV absorbers + HALS — no yellowing in the long term
The same DNA as the whole LuminaCast range.
Every LuminaCast system is made at DIPON's own production site in Germany: UV absorbers + HALS additives against yellowing, a formulation free of substances on the sVHC and CoRAP lists, and degassing components more than 70 % from renewable sources.
- UV absorbers + HALS — no yellowing in the long term
- Free of sVHC and CoRAP substances
- The systems in the range combine in a project — each has its role
Parameters you can rely on
Measured at 23 °C, 200 g, 20 mm layer — source: DIPON TDS
Compatible with wood, concrete, glass, metal, glass and carbon fibre fabrics, natural stone, silica sand, marble and granite.
Your first attempt will work out too
Check the temperature
Material and surroundings at room temperature. High temperature = fast exotherm, yellowing and cracks.
Test the substrate
A preliminary compatibility test of the materials you are going to embed.
Weigh out exactly 2:1
Always by weight (100:50). Maximum deviation 0.1 % — more means a sticky film or a soft casting.
Mix twice for 3–4 minutes
Mix → pour into a clean container → mix again. Max. 300 rpm, ideally with with an Allway Helix mixer.
Create without rushing
50 minutes for lines, textures and transitions — the artwork holds. You can demould after 16–24 hours.
⚠️ The most common mistake
Never mix by eye straight from bottles A and B. An inaccurate ratio = incomplete curing. Always weigh both components to the gram. Cleaning tools: acetone or universal thinner, immediately after use.
A set for resin art — resins that belong together
One painting, four roles: base, paint, precise detail and effects. Combine them.
| LuminaCast 3Crystal FlowDetail | LuminaCast 6Art FlowDetail | LuminaCast 7 ★Design FlowThis product | LuminaCast 10Cell FlowDetail | |
|---|---|---|---|---|
| Role in the project | Laminating and substrates | Painting techniques and top coat | Precise design, thin layers | Cell effects and ocean waves |
| Max. casting thickness | 10 mm | 20 mm | 20 mm | 20 mm |
| Working time | 35 min | 50 min | 50 min | 50 min |
| Viscosity (23 °C) | 140 mPa·s | 4100 mPa·s | 5500 mPa·s | 2500 mPa·s |
📊Compare the whole LuminaCast rangeAll 10 hardeners — viscosity, working time and casting thickness in one clear table▼
| Type | Viscosity* (23 °C) | Working time** | Max. casting thickness | Use |
|---|---|---|---|---|
| LC 1 Fast Set Primer | 120 mPa·s | 15 min | 7 mm | priming and sealing coat for wood, overpour after 60–120 min |
| LC 2 Coaster Cast | 290 mPa·s | 35 min | 15 mm | highly transparent embedding and shapes |
| LC 3 Crystal Flow | 140 mPa·s | 35 min | 10 mm | laminating & resin art |
| LC 4 Gem Flow | 890 mPa·s | 55 min | 20 mm | art & embedding, thicker pours |
| LC 5 Radiant Flow | 1330 mPa·s | 60 min | 20 mm | art & embedding, slower flow |
| LC 6 Art Flow | 4100 mPa·s | 50 min | 20 mm | painting techniques, top coat, sealing |
| LC 7 Design Flow ★ | 5500 mPa·s | 50 min | 20 mm | special spreading, thin layers |
| LC 8 Table Flow | 70 mPa·s | 180 min** | 5 cm | river tables, lamps, larger castings |
| LC 9 Ocean Flow | 50 mPa·s | 240 min** | 10 cm | river tables and very large castings |
| LC 10 Cell Flow | 2500 mPa·s | 50 min | 20 mm | cell effects, Petri art |
* Viscosity at 23 °C — it rises sharply as the temperature drops. ** Measured on 200 g; LC 8 and LC 9 on 500 g / 9 cm. Time to max. exotherm ≈ 2× the working time.
★★★★★ from those who already create
„A quality resin, the right density for a “Geode” design.“
Olena J. · verified purchase
„A great resin, mainly for smaller products!“
Martin O. · verified purchase
„My TOP resin.“
Květoslava M. · verified purchase
„A great thick epoxy for making things. It does not run as much as other thinner types and is nice to work with.“
Klaudia P. · verified purchase
„The resin is high quality and very nice to work with. The first attempt by our little eight-year-old artist, in the form of coasters.“
Aleš N. · verified purchaseHow much Design Flow resin do you need?
Enter the dimensions of your casting — we will calculate the amount, the component ratio and the best pack combination.
Frequently asked questions
How thick a layer can I pour?
1–20 mm in a single layer at 20 °C. Next layer after 12–16 hours.
How does it differ from other thick systems?
Design Flow has the highest viscosity in the whole range (5500 mPa·s) — it is for work where truly nothing may spread or drift.
When can I take the casting out of the mould?
Demoulding after approx. 16–24 hours at 23 °C.
How much will 3 kg cast?
3 kg of mixture (components A + B) equals approximately 2.8 l of casting (density 1.07 kg/l). The calculator above works out the exact amount for your project.
Why is 3 kg the most popular pack?
It is the most versatile balance of quantity and storage — approx. 2.8 litres of mixture covers most common projects.
Your design starts here.
Additional parameters
| Category: | Epoxy Resins |
|---|---|
| Weight: | 3.24 kg |
| ? Processing time: | Medium |
| Epoxy system: | LuminaCast 7 |
| Colour: | Clear, Highly transparent |
| Package weight: | 3 Kg |
| Refractive index: | > 1,59 |
| Food contact: | Yes |
| Max casting thickness: | 2 cm |
| ? UV Resistance: | Yes, Maximum |
| ? Temperature resistance: | 70 °C |
| ? Hardness: | 72 ShD |
| Type of use: | Jewellery making, Making trays and platters, Casting, Art, Geode Art, Petri Art, Floors, Floor sealing, 3D floors, 3D floor finishing, Art paintings, Artistic tumbler design, Furniture finishing, Mirror-gloss surfaces, Epoxy table surfaces |
| Casting size: | Small castings |
| ? Viscosity (density): | High - thick |
