DIPON LuminaCast 6 Art Flow 0,75 kg - High Viscosity Epoxy Resin, Thickness 20 mm
Code: 7298/000750Related products
Single-component solution designed for effective and quick removal and cleaning of surfaces from grease, oil, wax, dust, and similar contaminant.
Construction polypropylene tape for the production of epoxy molds. Length 55m, width 60mm
High quality polypropylene tape for excellent separation of casting from mold, 48 mm x 66 m
Product detailed description
DIPON LuminaCast 6 Art Flow
DIPON LuminaCast 6 Art Flow is a highly viscous (thick) clear epoxy resin specially developed for artists. Developed for the most demanding resin projects, this product combines not only excellent fluidity but also a flawless finish.
With a refractive index > 1.59, this product is among the most transparent epoxy resins on the market.

Key features of LuminaCast 6 Art Flow
- Mixing ratio 2:1 by weight.
- Casting height up to 20 mm and processing time up to 50 minutes depending on quantity and ambient temperature.
- Unmolding possible after 16 - 24 hours (23 °C).
- The next layer can be poured after approx. 12 - 16 hours (10 mm / 20 °C).
- It creates an incomparably smooth and shiny surface.
- The advanced formulation minimizes carbamate formation and ensures a flawless, blemish-free finish.
- High Viscosity Consistency : In addition to LuminaCast 7 Design Flow, LuminaCast 6 Art Flow has the highest viscosity for the slowest flow properties.
- For artists: Especially suitable for delicate floral designs, impressive geodes and projects where slow flow properties and perfect surface tension are important.
- Superior glossy finish: Achieve brilliant, mirror-smooth surfaces on every project.

Maximum UV protection

Casting height up to 20 mm
Up to 20 mm (20°C) in a single pour, depending on the amount of material and ambient temperature.
Workability up to 55 mins
Extended workability provides ample time for mixing, pigmenting, and degassing the mixture (at 23°C, 200g, 20 mm).
Mixing ratio 2:1 by weight
Very easy mixing and calculation of the correct amount of individual components.
Applications
- Highly transparent casts: Fabrication of transparent and aesthetically pleasing casts.
- Jewelry: designing exquisite jewelry, elegant trays and complex geode coasters.
- Sealing: creation and finishing of 3D floors, luxurious kitchen countertops and flawless epoxy table surfaces.
- 3D Flooring: elaboration of floors, including stunning 3D living room floors.
- Geode art: creation of avant-garde geode artworks with a main focus on "resin art".
- Petri-Art: Ideal system for Petri Art effects, combinable with colorants, especially "Alcohol-Inks".
- Repair: self-leveling surface treatments and precise repair applications.
- Art Images: Design of detailed resin art images by processes such as casting, brushing or rolling.
- For Furniture: refinement and protection of furniture finishes.
- High Gloss Results: Premium finishes in the renowned "piano lacquer" style.
- Doming: Production of high quality doming casts.
- Surfaces: Mirror-smooth and robust countertop finishes.
- Tumblers: Artful tumbler design.

General Characteristics
- Crystallization stable
- Bio-based ingredients in the epoxy resin
- Free from CoRAP and sVHC substances
- State-of-the-art base amines and additives with particularly low yellowing tendencies
- Mixing ratio: 2:1 by weight (A+B)
- Pot life (23°C), 200 grams, 2 cm: approx. 50 min. (23°C- > 40°C)
- Recommended material temperature (A+B): 20°- 24°C
- Recommended ambient temperature: 20°C - 25°C
- Dyn. Viscosity (mPa*s) 23°C: A 730 ± 50
- Dyn. Viscosity (mPa*s) 23°C: B 4100 ± 50
- Diamond Clear transparency
- Layer thickness (20°C): 1 - 20 mm
- 0% VOC content
- Excellent substrate wetting capability
- Very low shrinkage (<0.1%)
- Compatible with, e.g., wood, concrete, glass, metal, glass and carbon fiber fabrics, natural stone, quartz sand, marble, granite
Key Application Data
- Pot life at 23°C (200 grams, 20 mm): approx. 50 min.
- Time to max exothermy (tTmax) (23°C, 200 grams, 20 mm): approx. 100 min.
- Mixing duration: 3-4 min. + transfer and another 3-4 min for a uniform mixture
- Mixing ratio: 2:1 by weight (A+B)
- Recommended casting height (20°C): 0.1 cm - 2.0 cm (1 - 20 mm)
- Demoldable after (23°C): approx. 16 - 24 hrs.
- Next layer pourable after: approx. 12 - 16 hrs. at 20°C, 10 mm
- Minimum recommended mixing amount: 120 grams A+B
Additional parameters
| Category: | Epoxy Resins |
|---|---|
| Weight: | 0.88 kg |
| ? Processing time: | Medium |
| Epoxy system: | LuminaCast 6 |
| Colour: | Clear, Highly transparent |
| Package weight: | 1,5 Kg |
| Refractive index: | > 1,59 |
| Food contact: | Yes |
| Max casting thickness: | 2 cm |
| ? UV Resistance: | Yes, Maximum |
| ? Temperature resistance: | 70 °C |
| ? Hardness: | 72 ShD |
| Type of use: | Casting, Art, Petri Art, Floors, Floor sealing, 3D floors, 3D floor finishing, Art paintings, Artistic tumbler design, Furniture finishing, Mirror-gloss surfaces, Worktops |
| Casting size: | Small castings |
| ? Viscosity (density): | High - thick |
